How to set up Airflow

Apache Airflow is a workflow orchestrator for data pipelines. This guide shows a safe, minimal setup you can grow later.

1. Choose your installation path

If you want a quick local setup, use Docker Compose. If you are deploying to production, plan for a managed database and a proper executor.

Local (recommended for POC):

• Docker
• Postgres
• LocalExecutor

Production (baseline):

• Postgres or MySQL
• Redis (for Celery)
• CeleryExecutor or KubernetesExecutor

2. Local setup with Docker Compose

1. Create a new folder and copy the official Airflow docker-compose.yaml.
2. Set the required environment variables in a .env file.
3. Initialize the database and create an admin user.

Example commands:

mkdir airflow-poc
cd airflow-poc
curl -LfO 'https://airflow.apache.org/docs/apache-airflow/2.8.0/docker-compose.yaml'
mkdir -p ./dags ./logs ./plugins

echo "AIRFLOW_UID=50000" > .env

docker compose up airflow-init

docker compose up -d

Once it is running, open http://localhost:8080 and log in.

3. Create your first DAG

Inside ./dags, create a simple DAG file:

from airflow import DAG
from airflow.operators.bash import BashOperator
from datetime import datetime

with DAG(
    dag_id="hello_airflow",
    start_date=datetime(2024, 1, 1),
    schedule="@daily",
    catchup=False,
) as dag:
    task = BashOperator(
        task_id="print_date",
        bash_command="date",
    )

You should see it in the UI and be able to trigger it.

4. Move toward production

Key upgrades:

• Use a managed Postgres database.
• Store logs in S3 or GCS.
• Move to Celery or Kubernetes executor.
• Add secrets management (Vault, AWS Secrets Manager).
• Add monitoring and alerting.

5. Common pitfalls

• Forgetting to disable catchup for non-backfill workloads.
• Using SQLite in production.
• Running too many parallel tasks without tuning resources.

If you want, I can provide a production-ready reference architecture next.
